17.3" LILLIPUT Q18 4K 12G-SDI professional production studio monitor

LILLIPUT

17.3″ LILLIPUT Q18 4K 12G-SDI professional production studio monitor

Q18

€ 1 799.00

€ 2 230.76 (koos km)

Lilliput Q18 is a professional production studio monitor, packed with features and facilities for the professional photographer, videographer, or cinematographer. Compatible with a multitude of inputs – and featuring the option of a 12G SDI and 12G-SFP Fiber Optic input connection for broadcast quality monitoring, It also features Audio Vectoring using a Lissajous graph shape allowing you to visualize the depth and balance of a stereo recording.It also support remote control via RS422, GPI, LAN port .

Display: 17.3 inch, 3840 X 2160, 400nits
Input: 12G-SDI, 12-SFP, HDMI 2.0
Output: 12G-SDI, HDMI 2.0
Remote Control: RS422, GPI, LAN
Features: Quad View, 3D-LUT, HDR, Gammas, Remote Control, Audio vector, Camera Auxiliary Functions.

Loe edasi

Saadavus: Saadavus: VÕTA ÜHENDUST Tarneajaks on tavaliselt 1–2 nädalat, aga täpsema teabe saamiseks võtke meiega ühendust.

Meie poolt heaks kiidetud

Tasemel kvaliteet

Telli koju või astu läbi

Kirjeldus
Leidsid parema hinna?

DISPLAY	Panel	17.3″
	Physical Resolution	3840*2160
	Aspect Ratio	16:9
	Brightness	400 cd/m²
	Contrast	1200：1
	Viewing Angle	170°/170°（H/V)
	HDR	ST2084 300/1000/10000/HLG
	Supported Log Formats	SLog2 / SLog3 / CLog / NLog / ArriLog / JLog or User…
	Look up Table(LUT)support	3D LUT (.cube format)
	Technology	Calibration to Rec.709 with optional calibration unit
VIDEO INPUT	SDI	2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link)
	SFP	1×12G SFP+(Fiber module for optional)
	HDMI	1×HDMI 2.0
VIDEO LOOP OUTPUT	SDI	2×12G, 2×3G (Supported 4K-SDI Formats Single/Dual/Quad Link)
VIDEO LOOP OUTPUT	HDMI	1×HDMI 2.0
SUPPORTED FORMATS	SDI	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60…
	SFP	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080pSF 24/25/30, 1080i 50/60, 720p 50/60…
	HDMI	2160p 24/25/30/50/60, 1080p 24/25/30/50/60, 1080i 50/60, 720p 50/60…
AUDIO IN/OUT (48kHz PCM AUDIO)	SDI	16ch 48kHz 24-bit
	HDMI	8ch 24-bit
	Ear Jack	3.5mm
	Built-in Speakers	2
REMOTE CONTROL	RS422	In/out
	GPI	1
	LAN	1
POWER	Input Voltage	DC 12-24V
	Power Consumption	≤34.5W (15V)
	Compatible Batteries	V-Lock or Anton Bauer Mount
	Input Voltage(battery)	14.8V nominal
ENVIRONMENT	Operating Temperature	0℃~50℃
ENVIRONMENT	Storage Temperature	-20℃~60℃
OTHER	Dimension(LWD)	434mm × 294mm × 46mm
OTHER	Weight	3.9kg
