Features:
- 17″ UHD 4K monitor
- 1,000,000:1 contrast ratio
- 1000 cd/m² brightness
- Four 12G/6G/3G/HD-SDI inputs and four 12G/6G/3G/HD-SDI outputs
- One HDMI 2.0 input and one HDMI 2.0 output
- SD card slot for 3D LUTs
- One RJ45 Ethernet port
- One RJ45 GPI port
- 110mm VESA mounting on the back
- Thirty-six 1/4″-20 mounting threads on top and sides
- Smartrail mounting options
- 1/4″-20 and 3/8″-16 cheese-style mounting sticks included
SmallHD OS4.1:
- Internal calibration wizard
- Color pipe color-space formatting
- Settings dashboard for easy access to common settings
- Preconfigured pages
- Page tabs
- Customizable false color overlays
- Customizable 4K waveform with region-of-interest highlighting
- Improved function buttons
- Pixel zoom, focus assist, peaking
- Total UI overhaul
Power Options:
- One 3-pin XLR, 12-34V, 18A maximum
- Two 2-pin LEMO 12V, 2A outputs
- Two USB Type-A 5V, 2.4A outputs
- Two USB Type-C 5V, 1.5A outputs
- Separately available V-mount or Gold mount battery plates
- Requires 26V+ battery
- XLR and battery options are hot-swappable
