DREAMCHIP Targa encoder/decoder

Targa supports simultaneous dual video streaming: One High-Definition stream for broadcast audience and one Single-Definition stream for preview of e.g. multiple camera views, both H.264 encoded.

Targa core features

• HD-SDI Input: v1.1: Mini-Coax with BNC adapter v2.0: BNC
• HDMI Input (A, Standard) and HDMI Output (A, Standard)
• Audio Input (3.5mm) and Audio Output (3.5mm)
• Ethernet 10 / 100
• USB2.0 Host
• microSD Card Slot
• Antenna: SMA (2 x)
• Power Supply: v1.1: Mini-XLR + adapter cable, -v2.0: 2pol. DC jack 1
• Compression Algorithm: Baseline, Main and High Profile H.264
• Bit Rate: 200 Kbps to 30 Mbps
• Built-in Video Scaler and Deinterlacer
