Avenger couplers are perfect for carrying heavy loads. They are characterized by being the perfect mix between strength and durability and most of them also comply with TUV SUD safety standards.
The Avenger C345BK-1 Barrel Clamp in black is made with gravity cast aluminum, has a built in 28 mm/ 1 1/8 inch junior receiver, a 16 mm/ 5/8 inch baby pin with a 1/4” threaded top and a 16 mm/5/8 inch receiver. This barrel clamp is capable of mounting pipes or tubes ranging from 42 – 52 mm/1.65 – 2.05 inch and easily locks into place using a T-Knob The baby attachment can support loads up to 40 kg/88.2 lb while the junior receiver can take capacities up to 300 kg/661.4 lb. The C345-1 includes a safety cable with locking pin to secure attachments that are mounted in the junior receiver. TÜV SÜD certified.
Recommended Accessories: C155, C155-01, C155-02 E200, FF3276, A2029, C590, C626, C590
- Weight: 0.95 kg
- Attachment 01: 1 1/8″ (28mm) socket – Payload 300 Kg, 5/8″ (16mm) socket – Payload 40 Kg, 5/8″ (16mm) stud – Payload 40 Kg
- Length: 3 cm
- Certification: TUV
- Clamp Range – Max. (Round Tube): 52 mm
- Clamp Range Min Round Tube: 42 mm
- Colour: Black
- Material: Aluminium
