The Blackmagic Design Ultimatte Smart Remote 4 G2 is a professional hardware controller with a 10.1″ touchscreen, rotary encoders, and Ethernet connectivity, designed to control up to eight Ultimatte processors with an intuitive, user-friendly interface for real-time chroma key workflows.
The Blackmagic Design Ultimatte Smart Remote 4 G2 is a powerful and ergonomic control surface built for managing advanced chroma key workflows using Ultimatte processors. Designed by Blackmagic Design, this second-generation model offers enhanced connectivity, improved usability, and seamless integration into professional broadcast and virtual production environments.
Capable of controlling up to eight Ultimatte units simultaneously via high-speed 10/100/1000 Mb/s Ethernet, the Smart Remote 4 G2 provides centralized control for complex multi-camera setups. Its large 10.1-inch capacitive touchscreen LCD (1280 × 800 resolution) delivers clear visual feedback and intuitive navigation, while eight high-precision rotary encoder knobs allow for fine-tuned parameter adjustments.
The controller features dedicated unit selection buttons, preset controls, and On Line/On Air indicators for each connected device, enabling operators to quickly monitor and manage multiple Ultimatte processors in real time. The addition of HDMI Full HD output allows external monitoring, while upgraded USB-C ports support modern peripheral connectivity.
Running on the Blackmagic Operating System, the interface is optimized for speed and ease of use. Features such as “Monitor Out Views” provide instant access to key functions from any menu, improving workflow efficiency during live production.
The Smart Remote 4 G2 is fully compatible with current Ultimatte 12 processors, including 8K, 4K, HD, and HD Mini models, making it a versatile solution for broadcast studios, live events, and virtual production environments where precise chroma key control is essential.
Key Features
-
Controls up to 8 Ultimatte units via Ethernet
-
10.1″ capacitive touchscreen LCD (1280 × 800)
-
8 rotary encoder knobs for precise adjustments
-
Dedicated unit selection and preset buttons
-
On Line and On Air indicators per unit
-
HDMI Full HD output for external monitoring
-
USB-C connectivity for modern peripherals
-
Gigabit Ethernet (10/100/1000 Mb/s) support
-
Blackmagic Operating System for intuitive workflow
-
Ergonomic design with adjustable stand
-
1× Blackmagic Design Ultimatte Smart Remote 4 G2
-
Power cable
-
User documentation
General
-
Compatibility: Ultimatte 12 8K / 4K / HD / HD Mini
-
Color: Black
Controls
-
8 × Rotary encoder knobs
-
8 × Unit ID buttons
-
5 × Preset buttons
-
1 × File clear button
Display
-
Type: LCD touchscreen
-
Size: 10.1″
-
Resolution: 1280 × 800
-
Touch: Capacitive
Inputs / Outputs
-
USB:
-
2 × USB-C 2.0
-
1 × USB-C 3.x
-
-
Ethernet: 2 × RJ45 (10/100/1000 Mb/s)
-
Video Output: 1 × HDMI (up to 1080p)
Wireless
-
Wi-Fi supported
Power
-
Input: 100–240V AC, 50/60 Hz
-
Power Consumption: 24W
Environmental
-
Operating Temperature: 0°C to 35°C
-
Storage Temperature: -20°C to 60°C
-
Humidity: Up to 90%
Physical
-
Dimensions: 431.8 × 175.3 × 104.1 mm
-
Weight: 4.21 kg
